Liquid Tender Trailers

Save time, take it to the field with you!

  • 12 Volt Power available on front and back
  • Air Couplers
  • Easy on & off stairs
  • Customizable for your needs!
36'38'40'42'48' Tandem48' Triple53' Triple
Width102"102"102"102"102"102"102"
Liquid Capacity4,700-6,500 gal.4,700-6,500 gal.4,700-6,500 gal.4,700-6,500 gal.4,700-6,500 gal.4,700-6,500 gal.4,700-6,500 gal.
AxlesClosed Tandem Hutch Spring Ride (Optional Air Ride)
2 x 22,500 (ABS on 1 axle)
Closed Tandem Hutch Spring Ride (Optional Air Ride)
2 x 22,500 (ABS on 1 axle)
Closed Tandem Hutch Spring Ride (Optional Air Ride)
2 x 22,500 (ABS on 1 axle)
Closed Tandem Hutch Spring Ride (Optional Air Ride)
2 x 22,500 (ABS on 1 axle)
Closed Tandem Hutch Spring Ride (Optional Air Ride)
2 x 22,500 (ABS on 1 axle)
Triple Axle SAF Holland Air Ride ONLY
3 x 23,000 (ABS on 1 axle)
Triple Axle SAF Holland Air Ride ONLY
3 x 23,000 (ABS on 1 axle)
Deck Length9'6"11'6"13'6"15'6"21'21'25'4"
GVWR63,500 lb.68,000 lb.68,000 lb.68,000 lb.68,000 lb.77,500 lb.77,500 lb.
Tare Weight12,980 lb.13,140 lb.13,580 lb.13,900 lb.15,920 lb.16,860 lb.17,500 lb.

Storage bins weigh 140 bs. each.

Tank ladders add 56 lbs. each.

Features

  • 24” King pin
  • Exterior mating surfaces are caulked prior to paint to prevent rust
  • 2 aluminum steps with handrails
  • Black plastic liquid tanks eliminate light from reaching the interior contents preventing algae and microbes growth
  • 16.5” x 7” brake size, color coded
  • Midship turn signals
  • 255/70 R22.5 - 16 ply DOT tires and wheels
  • Rubber mounted LED lights, DOT approved tape

Main Beam Sizes

Web1/4” high grade 100,000 yield steel
Flange3/8” x 5” high grade 100,000 yield steel
Cross members4” x 3.2# 80,000 yield jr. I-beam on 16" centers
Side rails
6” x 8.2# structural C channel
Rub rail
2” x 3/8” flat steel
Beam rating
50,000 lbs per 10 linear feet

Decking

Material1 1/8" x 7" Apitong flooring
Transition Drop
19.5" between decks

Options

  • Air ride suspension for 36’, 38’, 40’, 42’ and 48' tandem trailer and standard on 48' and 53' triple axle
  • ABS installed on second axle
  • Disc brakes available on air ride suspension only
  • Center Deck tie downs
  • 12 Volt power front or front and rear
  • Air coupler - front of work deck or front and rear of work deck
  • Storage bins: Steel Metal or Aluminum Toolbox. Up to 2 on passenger side and 2 on drivers side - any combination
  • Aluminum rims, hub piloted (each)
  • Custom paint color (red, gray, white, blue)

Tank Options

  • Den Hartog end drain and center sump drain tanks 2350, 2750, 3250 gallons (ladders offered on 3250 gallon tank)
  • Enduraplas center sump drain tanks 2800 and 3200 gallons (ladders offered on 3200 gallon tank)

All tanks come standard with sight gauges, 3” drain fittings, and are black in color


The Corrosion Solution CORSOL® corrosion solutions are used to protect our steel components that need it the most from the devastating effects of corrosion undercutting and blistering. The PRP® Industries’ METAL POLYMERIZATION process utilizes strategically paired chemicals andprocedures, resulting in a finish guaranteed not to undercut and blister.

Field-Proven TestingWashington State Department of Transportation is particularly hard on its snow removal equipment. Exposure to months of harsh conditions and corrosive road salt while operating in mountainous regions is why we chose their equipment to field test CORSOL® corrosion solutions. The two salt spreader trucks shown below were brand new in 2008 and have since operated continuously out of the same facility.

Corsol paint trucks
